RC3015FB World Top 10 Selling Enclosed Type Steel Sheet Fiber Laser Cutting Machine Cut Steel Plate


Features:

1.Whole Machine welded bed structure,Stable performance,could ensure the stable operation of equipment
2.After high temperature heat treatment Machine bed, adopt large Gantry milling accuracy process, ensure machine bed stability and smoothness.
3.High quality, high efficiency fiber laser producer. low processing cost and energy conservation and environment protection
4.Servo drive,The structure of the machine tool adopts rack and pinion drive,Ensure equipment high speed , high accuracy, and high reliability
5. Fast delivery 1kw high power CNC metal sheet pipe fiber laser cutting machine, 1000W, 1500W, 2000W, 3000W, 6000W, 8000W fiber laser power available
6. laser cutting machine adopts MAX, RAYCUS fiber laser source brand available
7. High speed, high accuracy, stable performance, best quality


Products Parameter


No.

ITEM

DESCRIPTION

01

Machine Structure

Full Enclosed Fiber Laser Cutting Machine

02

Working Area

3000*1500mm

03

Laser Source

Raycus / MAX / JPT / IPG/RECI

04

Laser Cutting Head

Switzerland Raytools Auto Focus Bm110

05

Transmission System

Dual Drive ,Precise Rack & Pinion

06

Guide Rail

Taiwan Hiwin

07

Rack &Pinion

Taiwan Yyc

08

Speed Reducer

Japan Shimpo Reducer

09

Motor &Drives

Japan Yaskawa Servo System

10

Water Chiller

S&A

11

Control System

Cypcut

12

Proportional Valve

Jpan Smc

13

Alxiliary Parts

Exhaust Fan

14

Electrical Component

Schineider France

15

Computer

Yes

16

Auto Lubrication

Yes

17

Remote Controller

Yes

18

Automatic Voltage Stabilizer (50Kva)

Yes

19

X/Y Axis Repeated Position Precision

+-0.03mm

20

Machine Net Weight

2000kgs

21

Voltage

380V,50Hz

Application Materials:

Fiber Laser Cutting Equipment is suitable for metal cutting like Stainless Steel Sheet, Mild Steel Plate,
Carbon Steel Sheet, Alloy Steel Plate, Spring steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, If you equipped with the rotary axis, Metal Plate, Tubes and Pipes, all ok.
Application Industries:
Rakoncnc Fiber Laser Cutting Machines are widely used in manufacture Billboard, Signs, Advertising, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, Glasses Frame, Electronic Parts, Nameplates, etc.

Sample Display:

Mainly used for cutting carbon steel, silicon steel, stainless steel, aluminum alloy, titanium alloy, galvanized steel sheet, pickling board, aluminum zinc plate, copper and many kinds of metal materials cutting and so on.
